Ti Series

Titanium alloys are alloys that contain a mixture of titanium and other chemical elements. Such alloys have very high tensile strength and toughness. They are light in weight, have extraordinary corrosion resistance and the ability to withstand extreme temperatures.

​

Titanium alloys are generally classified into four main categories. Commercially Pure Titanium Grade 1 is the softest titanium and has the highest ductility. It has good cold forming characteristics and provides excellent corrosion resistance. It also has excellent welding properties and high impact toughness.

​

Grade 2 has moderate strength and excellent cold forming properties. Grade 3 is stronger and less formable than Titanium Grades 1 and 2. Grade 4 is stronger than CP Grades 2 & 3 – it can be cold formed, but has lower ductility.

Available Forms

Black Washed Wall

Application

Applications for Ti series include:

​

  • Hydraulic & Instrumentation Tubing

  • Chemical Processing Equipment

  • Marine & Airframe Application

  • Power Plant Cooling System Component

  • Medical Devices

Chemical Composition (max)

​

Ti 1

Ti 2

Ti 3

Ti 4

N

0.03

0.03

0.05

0.05

C

0.08

0.08

0.08

0.08

Ti

99.5

99.3

99.2

99.0

Fe

0.20

0.30

0.30

0.50

O

0.18

0.25

0.35

0.40

H

0.015

0.015

0.015

0.015

Sizes & Specification

Forms



Coils

Sheets

Plates

Bars (Round)

Bars (Flat)

Bars (Hex)

Thickness (mm)

1.0 - 8.0

1.0 - 3.0

3.0 - 50.0

-

3.0 - 50.0

-

Length (mm)



-

2500 / 3000 / 5000 / 6000 / 6300

2500 / 3000 / 5000 / 6000 / 6300

5000 - 6000

5000 - 6000

5000 - 6000

Dia (inch/mm)

​

-

-

-

10mm - 200mm

10mm x 10mm - 100mm x 100mm

10mm x 10mm - 100mm x 100mm

Width (mm)

​

1250 / 1500 / 2000

1250 / 1500 / 2000

1250 / 1500 / 2000

-

-

-
